TM265 Low-Medium Chirp, 1kW

Share this product


The TM265LM, Chirp-ready transom mount is a perfect mid to deep-depth transducer. The huge bandwidth includes many of the most popular frequencies for targeting top gamefish. This 1 kW powerhouse delivers clear target details, bottom discrimination, as well as bait and game-fish separation at all depths.

The low-frequency band of 42 to 65 kHz provides deep-water performance down to 914 m (3000′). It is a good choice when scouting an area or fishing in deeper depths. The medium frequency from 85 to 135 kHz is excellent for identifying targets suspended close to the bottom, on structure, and within the water column.

  • Depth and fast-response water-temperature sensing
  • 1 kW of power for great deep to mid-depth performance
  • Low frequency: 42 to 65 kHz
    • 25° to 16° port-starboard beamwidth
    • Maximum depth of 914 m (3000′)
  • Medium frequency: 85 to 135 kHz
    • 16° to 11° beamwidth
    • Maximum depth of 457 m (1500′)
  • 73 kHz of total bandwidth from one transducer
  • Covers popular fishing frequencies of 50, 88, and 107 kHz plus everything else in the bandwidths
  • Transom mount stainless steel bracket for installation on boats of all propulsion types
  • SEALCAST, seamless, urethane housing for long life in the water
  • Also available as in-hull (M265LM), cavity/welded-tank (CM265LM), thru-hull (B265LM), and pocket (PM265LM) mounts
  • Patented Xducer ID® technology
    Cable-Length: 10 m (33′)
    Common Use: Fishing, Commercial Fishing
    Connector: Furuno 12-Pin
    Country of Origin: USA
    Display Connector: 12F
    Frequency Band: Low-Medium
    Functions: Depth, Temperature
    Housing: Urethane/Stainless Bracket
    Hull Material: Compatible w/ all hull materials
    Low Frequency: 42-65 kHz
    Low Frequency Beamwidth: 25°-16°
    Material: Urethane
    Max Depth: Low frequency- 914 m (3000′), Medium frequency- 457 m (1500′)
    Max Vessel LOA: Up to 10 m (33′)
    Medium Frequency: 85-135 kHz
    Medium Frequency Beamwidth: 16°-11°
    Mix and Match Series: 12-Pin Chirp
    Mounting Style: Transom
    Power Rating: 1 kW
    Sensor Connector: MMC
    Single or Dual Frequency: CHIRP-Ready Dual-Band
    Tilted Element: No
    Transom Angle: 3° to 21°
    Weight: 4 kg (8.9 lb.)
