TM265 Low-High Chirp, 1kW

Share this product


We know that specific frequencies excel at detecting certain species of fish: Bluefin Tuna—60 kHz, squid—133 kHz, and cod—175 kHz. The TM265LH transducer includes all these frequencies plus every other frequency in the high and low bandwidths. This powerhouse delivers excellent resolution, bottom discrimination, and bait and game-fish separation at all depths.

Airmar’s TM265LH is packed with a seven-element, low-frequency array that operates between 42 and 65 kHz for excellent deep-water performance. The high-frequency ceramic operates between 130 and 210 kHz with a narrow, 10° to 6°, beam—perfect for picking apart structure and pinpointing tight-holding fish in structure.

  • Depth and fast-response water-temperature sensing
  • 1 kW of power for great deep-water performance
  • Low frequency: 42 to 65 kHz
    • 25° to 16° port-starboard beamwidth
    • Maximum depth of 914 m (3000′)
  • High frequency: 130 to 210 kHz
    • 10° to 6° beamwidth
    • Maximum depth of 304 m (1000′)
  • 103 kHz of total bandwidth from one transducer
  • Covers popular fishing frequencies of 50 and 200 kHz plus everything else in the bandwidth
  • Transom mount, stainless steel bracket for installation on boats of all propulsion types
  • SEALCAST, seamless, urethane housing for long life in the water
  • Also available as cavity/welded-tank (CM265LH), thru-hull (B265LH), in-hull (M265LH), and pocket (PM265LH) mounts
  • Patented Xducer ID® technology
    Cable-Length: 10 m (33′)
    Common Use: Fishing, Commercial Fishing
    Connector: Furuno 12-Pin
    Country of Origin: USA
    Display Connector: 12F
    Frequency Band: Low-High
    Functions: Depth, Temperature
    High Frequency: 130-210 kHz
    High Frequency Beamwidth: 16°-11°
    Housing: Urethane/Stainless Bracket
    Hull Material: Compatible w/ all hull materials
    Low Frequency: 42-65 kHz
    Low Frequency Beamwidth: 25°-16°
    Material: Urethane
    Max Depth: Low frequency- 914 m (3000′), High frequency- 304 m (1000′)
    Max Vessel LOA: Up to 10 m (33′)
    Mix and Match Series: 12-Pin Chirp
    Mounting Style: Transom
    Power Rating: 1 kW
    Sensor Connector: MMC
    Single or Dual Frequency: CHIRP-Ready Dual-Band
    Tilted Element: No
    Transom Angle: 3° to 21°
    Weight: 4 kg (8.9 lb.)
