TM185 High Wide Chirp, 1kW

Share this product


Get more coverage under your boat with Airmar’s unique, wide-beam, high-frequency, Chirp-ready TM185HW. The high-frequency band operates across a range of 150 to 250 kHz and has a fixed 25° beam. The high-frequency band yields superior shallow-water performance, bottom detail, and fish-target separation. The constantly wide beam provides twice the coverage for detecting fish in the upper-water column and clear fish arches on the display compared to most high-frequency, narrow-beam transducers. The high wide is the ideal choice for both inshore and pelagic fishing, where resolution and maximum coverage are essential down to 152 m (500′).

  • Depth and fast-response water-temperature sensing
  • 1 kW of power
  • High frequency: 150 to 250 kHz
    • Constant 25° beamwidth
    • Maximum depth of 152 m (500′)
  • 100 kHz of total bandwidth from one transducer
  • Covers popular fishing frequency of 200 kHz plus everything else in the bandwidth
  • Stainless steel bracket for installation on outboard or inboard/outboard powered boats
  • Recommended for use on planing and displacement hulls
  • SEALCAST, seamless, urethane housing for long life in the water
  • Also available as thru-hull Tilted Element (B175HW)(SS175HW), thru-hull with fairing (B285HW), and in-hull (M285HW) mounts
  • Patented Xducer ID® technology
    Cable-Length: 10 m (33′)
    Common Use: Leisure/Yachting, Fishing
    Connector: Humminbird 21-Pin
    Country of Origin: USA
    Display Connector: 21HB
    Freq Hi Wide: 150-250 kHz
    Frequency Band: High Wide
    Functions: Depth, Temperature
    High-Wide Beamwidth: 25°
    Housing: Urethane/Stainless Bracket
    Hull Material: Compatible w/ all hull materials
    Material: Urethane
    Max Depth: 150 m (500′)
    Max Vessel LOA: Up to 10 m (33′)
    Mix and Match Series: 12-Pin Chirp
    Mounting Style: Transom
    Power Rating: 1 kW
    Sensor Connector: MMC
    Single or Dual Frequency: CHIRP-Ready Single-Band
    Tilted Element: No
    Transom Angle: 3° to 21°
    Weight: 4.2 kg (9.2 lb.)
