TM165 High Wide Chirp, 600W

Share this product


Maximize the coverage under your boat and see what you’ve been missing. Airmar’s TM165HW features a high-frequency range of 150 to 250 kHz and a super-wide beamwidth, averaging 30°, providing maximum coverage across the frequency band. High frequency delivers superior shallow-water performance, bottom detail, and fish-target separation. In addition to improving the performance of Chirp-capable fishfinders, anglers using this wide-beam transducer will achieve three-times the coverage compared to standard, high-frequency, Chirp-ready transducers.

Wide beamwidth, together with the high-frequency range, provides vast bottom coverage and precise fish detection in the upper-water column that can sometimes go unseen with narrow-beam transducers. Airmar’s wide-beam format also creates crisper and larger return images on the display.

  • Depth and fast-response water-temperature sensing
  • 600 W of power
  • High frequency: 150 to 250 kHz
    • Super-wide 30° average beamwidth
    • Maximum depth of 152 m (500’)
  • 100 kHz of total bandwidth from one transducer
  • Covers popular fishing frequency of 200 kHz plus everything else in the bandwidth
  • Plastic release bracket protects sensor from frontal impact
  • Chemical and impact-resistant plastic housing
  • Recommended for planing hulls
  • Patented Xducer ID® technology
    Cable-Length: 9 m (30′)
    Common Use: Leisure/Yachting, Fishing
    Connector: Airmar 12-Pin (MMC)
    Country of Origin: USA
    Display Connector: Cable Required
    Frequency Band: High Wide
    Functions: Depth, Temperature
    High Frequency: 150-250 kHz
    High-Wide Beamwidth: 30°
    Housing: Plastic Bracket
    Material: Plastic
    Max Depth: 150 m (500′)
    Max Vessel LOA: Up to 8 m (26′)
    Mix and Match Series: 12-Pin Chirp
    Mounting Style: Transom
    Power Rating: 600 W
    Sensor Connector: MMC
    Single or Dual Frequency: CHIRP-Ready Single-Band
    Tilted Element: No
    Transom Angle: 2° to 22°
    Weight: 0.5 kg (1.1 lb.)
