R599 Low-Medium Chirp, 3kW

Share this product


Having the right tool for the job makes the job easier and provides better results. The right tool for covering deep-water haunts of swordfish, tuna, and other species is a 2 to 3 kW, low to medium-frequency transducer. The Chirp-ready R599LM delivers the deep-water performance of the low frequency down to 3048 m (10000′) plus the detailed returns produced by the narrower beams of the medium band.

Chirp technology shows 5 to 10 times-greater detail and resolution than conventional frequencies. The R599LM transmits across the low frequency bandwidth of 28 to 60 kHz and the medium frequency from 80 to 130 kHz. This transducer delivers up to 82 kHz of total bandwidth in a single installation.

The transducer is installed in the included tank which is cut to the boat’s deadrise angle and affixed inside the hull. When the transducer is placed inside the tank, it is properly oriented for optimal performance. The R599LM is a popular choice for customers not wanting to drill a hole in their hull and for trailered or multi-hull boats.

  • Depth only
  • 2 to 3 kW of power for superior deep-water performance
  • Low frequency: 28 to 60 kHz
    • 23° to 9° port-starboard beamwidth
    • 11° to 5° fore-aft beamwidth
    • Maximum depth of 3048 m (10000′)
  • Medium frequency: 80 to 130 kHz
    • 13° to 8° beamwidth
    • Maximum depth of 914 m (3000′)
  • 82 kHz of total bandwidth from one transducer
  • Covers popular fishing frequencies of 38, 50, 88, and 107 kHz plus everything else in the bandwidth
  • Urethane transducer housing with plastic mounting tank
  • Also available as thru-hull external (R509LM) and cavity/welded-tank (CM599LM) mounts
  • Patented Xducer ID® technology
    Acoustic Window: Epoxy/urethane
    Cable-Length: 15 m (49′)
    Common Use: Fishing, Commercial Fishing
    Connector: Bare Wire
    Country of Origin: USA
    Cross Reference: A80213
    Deadrise Range: 0° to 22°
    Display Connector: 0
    Frequency Band: Low-Medium
    Functions: Depth, Depth, Temperature
    Hull Material: Solid fiberglass only
    Low Frequency: 28-60 kHz
    Low Frequency Beamwidth: 23°-9°
    Material: Urethane
    Max Deadrise: Up to 22° (short side), up to 12° (long side)
    Max Deadrise Angle: 22°
    Max Depth: Low frequency- 3048 m (10000′), Medium frequency- 914 m (3000′)
    Max Vessel LOA: 12 m (40′) and above
    Medium Frequency: 80-130 kHz
    Medium Frequency Beamwidth: 13°-8°
    Mounting Style: In-Hull
    Power Rating: 2-3 kW
    Single or Dual Frequency: CHIRP-Ready Dual-Band
    Tilted Element: No
    Weight: 19.7 kg (43.4 lb.)
