Having the right tool for the job makes the job easier and gives better results. The right tool for covering deep-water haunts of swordfish, tuna, and other species is a 2 kW, low to medium-frequency transducer. The Chirp-ready R111LM delivers the deep-water performance of the low frequency down to 1829 m (6000′) plus the detailed returns produced by the narrower beams of the medium band.

Chirp technology shows 5 to 10 times-greater detail and resolution than conventional frequencies. The R111LM transmits across the low frequency bandwidth of 38 to 75 kHz, and the medium frequency from 80 to 130 kHz. This transducer delivers up to 87 kHz of total bandwidth in a single installation.

The transducer is installed in the included tank which is cut to the boat’s deadrise angle and affixed inside the hull. When the transducer is placed inside the tank, it is properly oriented for optimal performance. The R111LM is a popular choice for customers not wanting to drill a hole in their hull and for trailered or multi-hull boats.

  • Depth only
  • 2 kW of power for outstanding deep-water performance
  • Low frequency: 38 to 75 kHz
    • 19° to 10° port-starboard beamwidth
    • 10° to 5° fore-aft beamwidth
    • Maximum depth of 1829 m (6000′)
  • Medium frequency: 80 to 130 kHz
    • 13° to 8° beamwidth
    • Maximum depth of 914 m (3000′)
  • 87 kHz of total bandwidth from one transducer
  • Covers popular fishing frequencies of 38, 50, 88, and 107 kHz plus everything else in the bandwidth
  • Urethane transducer housing with plastic mounting tank
  • Also available as thru-hull external (R109LM) and pocket/keel/welded-tank (PM111LM) mounts
  • Patented Xducer ID® technology
    Cable-Length: 15 m (49′)
    Common Use: Fishing, Commercial Fishing
    Connector: Bare Wire
    Country of Origin: USA
    Cross Reference: A80134
    Deadrise Range: Up to 25° with fairing
    Display Connector: No Connector
    Frequency Band: Low-Medium
    Functions: Depth
    Hull Material: Solid fiberglass only
    Low Frequency: 38-75 kHz
    Low Frequency Beamwidth: 10°x19°-5°x10°
    Material: Urethane
    Max Deadrise: Up to 22° (short side), up to 12° (long side)
    Max Deadrise Angle: 22°
    Max Depth: Low frequency- 1829 m (6000′), Medium frequency- 914 m (3000′)
    Max Vessel LOA: 8 m (25′) and above
    Medium Frequency: 80-130 kHz
    Medium Frequency Beamwidth: 13°-8°
    Mounting Style: In-Hull
    Power Rating: 2 kW
    Single or Dual Frequency: CHIRP-Ready Dual-Band
    Tilted Element: No
    Weight: 13.6 kg (30 lb.)
